    IS0 180 Electronic Charpy Impact Mechanical Testing Machine For Rubber Plastic

    Ask Lasest Price
    Brand Name : ZL
    Model Number : ZL-3016B
    Certification : ISO
    Price : Negotiable
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 100 set per month
    Delivery Time : 3-7 days
    • Product Details
    • Company Profile

    IS0 180 Electronic Charpy Impact Mechanical Testing Machine For Rubber Plastic

    IS0 180 Electronic Charpy Impact Mechanical Testing Machine For Rubber Plastic


    Introduce:

    Digital type Charpy Impact Tester for plastic pipes, plates, profiles and engineering plastics, fiberglass,

    ceramics, cast stone, insulation materials and other non-metallic materials resistant to impact toughness.


    Machine performance:


    Clamp jaws wedge from mouth, clamping freely, fast clamping, is the latest development of our new

    products.


    Standards: IS0 180, GB / T 1843, GB / T 2611,JB / T 8761


    Specifications:


    ModelDigital type Charpy Impact Tester
    Charpy energy1,2.75,5.5 J11,22 J
    Impact velocity3.5m/s3.5m/s
    Pendulum elevation150°
    Center-to-center distance of the pendulum sample335mm335mm
    Pendulum torque

    PL1=0.53590 Nm

    PL2.75=1.47372 Nm

    PL5.5=2.94744 Nm

    PL11=5.8949Nm

    PL22=11.7898Nm

    Impact of the blade radiusR=22±0.2mm
    Sample Size Type

    80*10*4mm

    63.5*12.7*3.2mm

    63.5*12.7*6.4mm

    63.5*12.7*12.7mm

    80*10*4mm

    63.5*12.7*3.2mm

    63.5*12.7*6.4mm 63.5*12.7*12.7mm


    Download Brief:
